Antenna Ku-band 384-CH TDD phased array antenna
- Array Size：384
- Frequency : 15.6 GHz-16.5GHz
- Polarization：Horizontal
- Antenna Gain：≥29dB (unweighted)
- EIRP (Normal Direction)： ≥81dBm
- G/T (Normal Direction)： ≥0dB/K
- Scan Range： Azimuth ± 45 °, Elevation ± 45 °
- First Sidelobe Suppression： ≤-12dB
- Duty Cycle： ≤ 20%
- PRF： 5KHz~ 50KHz
- Power Consumption: ≤350W(20% Duty cycle)@+28V
- Size: 350mm*230mm*45mm
- Weight:≤4.4Kg
